High - Precision Drum Palletizer with Stainless Steel Drums for
Reliable Automation
Drum Palletizer
We provide professional Drum Palletizer that can accurately and
efficiently stack and arrange goods, significantly improving the
operational efficiency of warehousing and logistics.
The Drum Palletizer is an advanced automation system specifically
designed for the efficient and precise stacking of drums onto
pallets. This system is a powerhouse in warehousing and
manufacturing environments where the safe and orderly storage of
heavy drum containers is paramount.
TECHNOLOGICAL ADVANTAGE
High-Capacity Handling: Designed to manage the heavy load of filled drums with a high
level of accuracy.
Space-Efficiency: Maximizes the use of vertical space, allowing for compact storage
solutions in confined areas.
Safety: Equipped with multiple safety features to protect operators and
ensure secure drum handling.
PRODUCT FEATURES
Our Drum Palletizer is adaptable to various drum sizes and pallet
configurations, ensuring it can accommodate the diverse needs of
different industries. It is engineered to handle the weight and
dimensions typical of standard drum types with ease.
PRODUCT MATERIALS
The Drum Palletizer is constructed with robust stainless steel and
heavy-duty components to withstand the demands of heavy lifting and
repetitive motion. The materials are chosen for their strength and
resistance to the wear and tear of industrial use.
OPERATIONAL CONTROL
Featuring an intuitive control panel, the Drum Palletizer allows
operators to control the palletizing process with ease. The system
supports programmable patterns and sequences to cater to various
pallet configurations.
INSTALLATION and SETUP
The system is designed for straightforward installation and can be
easily integrated into existing production or storage workflows.
Its modular design allows for customization to fit specific
facility layouts.
SERVIC and SUPPORT
We provide comprehensive maintenance services to ensure the Drum
Palletizer remains in optimal condition. Our dedicated support team
is available to assist with any technical queries or service needs.
PRODUCT PARAMENTERS
Wrapping Height Max. | 2000 mm |
Packing Size Max. | W 1200 mm × L 1200 mm |
Efficiency | 40 - 60 loads/h |
Load Capacity | 2000 kg |
Turntable Height | 470 mm |
Turntable Diameter | 2000 mm |
Turntable Rotation Speed | 0 - 12 rpm, variable |
Film Delivery System | Powered Roller Pre-Stretch System Up to 250 - 300% |
Automatic Film Clamper and Cutter | Std. |
Roller Table Width (BF) | 1300 mm |
Conveyor Speed | 8 m/min, Constant |
Stretch Film | LLDPE Stretch Film in 500 mm width × 15 - 35 um thickness; Film
Reel in 76 mm core diameter × Max. 250 mm OD |
Air Supply | 6 - 8 kg/cm2 |
Voltage | 380 VAC 3 ph 50/60 Hz |
Power | 3.5 kw |
Machine Size | L 2950 mm × W 2000 mm × H 2950 mm |
Machine Weight | 1000 kg |
*It can be modified according to customer requirements.
